F4 Sabre was added to our line in 2019 as the first 4” Super FAT tire option . It is our flagship model for the 1000 Watt series and of course comes with all our best components and features as the top model in our high performance FAT tire - trail series! This includes our removable lithium battery (18Ah), oversized 150mm Renegade front suspension fork and Shimano hydraulic disc brakes!
Sabre comes with a high-powered 1000 Watt series motor and 40Amp controller system. In addition, the F4 comes standard with the latest Cycle Analyst 3 Computer Display which has lots of control features for speed, power levels and even cruise control. A wireless ignition component controls the system activation on/off. The motor system features the "Brute" version for higher torque and climbing power needed with the FAT tire edition.
Since the F4 requires a special wider suspension fork to accommodate the bigger 4" wheel / Tire, the unit has a more substantial wide stance and relative stability. Sabre is available only for sale direct to riders since it is not available in retail stores.
SO, for those willing to pay a little more for the radical FAT tire bad ass ride, F4 Sabre is the model of choice with added performance and for some – the Glide ride to own!
- 48V Power System
- Wireless Ignition System
- Air Ride Front Suspension
- 4" All-Terrain Tires
- QR Removable Axle
- Integrated Rear Fender With MTX Cargo Rack
- MTX Bag or Basket Integration
- 6061 Aluminum Frame with 600lb + Capacity
- Heat-Teated Powder Coated Frame
- Adjustable Handlebar Stem
- 26" Front End For Forgiving Ride
- Removable Lithium Battery for Counter-Top Charging
- 3A Quick-Charge Digital Charger
- Cycle Analyst Digital Control Panel
- C/A Programmable Speed and Power Variables
- C/A Cruise Control Options
- Easy-Glide Thumb Throttle
- Shimano Hydraulic Disc Brakes
- 203mm Rear Roter for Max Stopping
- 180mm Front Rotor for Balanced Stopping
- Non-Skid Oversized Footboard Deck
- 12V Parallel Wiring for Light System
- Optional 900 Lumen LED Head Light Kit
- Optional LED Strip Tail Lights Kit
- Optional LED Strip Light Accent Kit
- Optional 20Ah Lithium Battery - up to 30 Mile Range
| Motor |
|
| Volts |
48V |
| Watts |
1200W |
| Type |
Brushless |
| Geared |
No |
| Max Speed |
25 MPH |
| Controller |
|
| Type |
Digital |
| Volts / Watts |
48V / 1200 Watts |
| Max Current |
40 Amps |
| Computer Display |
|
| Cycle Analyst 3 |
Multi-Function - Speed, Power Settings, Cruise Control |
| Wheels / Tires |
|
| Wheels |
26x3" Front, 20x3" Rear |
| Tires |
26" Front, 20" Rear, 3" Street |
| Body |
|
| Length |
87 in. |
| Width |
28 in. |
| Height |
50 in. |
| Wheelbase |
63 in. |
| Maximum payload |
600+ lbs |
| Curb weight |
77.5 lbs |
| Battery |
|
| Type |
Lithium Ion |
| Charge Capacity |
18Ah |
| Riding Range |
22-27 Miles |
| Time to Charge |
3-4 Hours From Empty |
| LIGHT KITS |
|
Under-carriage Kit - L1  |
LED Strip Light Kit Installed - $195 |
Full Lights Kit - L2  + |
FR/RR Running lights + Under-carriage Kits Installed - $325 |
| BATTERY UPGRADE |
|
48V - 18Ah to 20Ah Lithium  |
Lithium - $275 |
| COMPUTER UPGRADE |
|
Computer Display  |
Cycle Analyst 3 - $185 |
| FRAME COLOR UPGRADE |
|
Custom Frame COlor  |
Powder-Coat / Heat-treat Custom Frame Color - $375 |
| CARGO OPTIONS |
|
Cargo Flatbed Trailer  |
125 LB Capacity, $325 |
MTX Zipper Trunk Bag  |
2 Versions From $49.95 |
MTX Wire Basket |
1 Model - $29.95 |
| LIGHT KIT |
|
| Trailer Light Kit |
Requires L1 or L2 Light Kit pre-Installed - $125 |
| HELMET |
|
Kali Unisex  |
3 Sizes - $25 |
| EXTRA BATTERIES |
|
| 48V - 18Ah Lithium |
Lithium - $775 |
48V - 20Ah Lithium  |
Lithium - $875 |
